Sea Level Rise

The best I can do to summarise the complex subject of secular ‘Sea Level Rise’ (SLR) is to start with Wikipedia (note that here, we define time as BP, ‘Before Present’, i.e., with a 1950 year shift compared to BC):

“eustatic sea level has fluctuated significantly over the earth’s history. The main factors affecting sea level are the amount and volume of available water and the shape and volume of the ocean basins. The primary influences on water volume are the temperature of the seawater, which affects density, and the amounts of water retained in other reservoirs like rivers, aquifers, lakes, glaciers, polar ice caps and sea ice. Over geological timescales, changes in the shape of the oceanic basins and in land/sea distribution affect sea level. In addition to eustatic changes, local changes in sea level are caused by tectonic uplift and subsidence.”

It is obviously difficult to differentiate eustatic SLR from crustal movements of the earth as our measuring instruments are placed on the earth. The best approach is to assess that water is supposed to remain ‘horizontal’ on a large basin like the Mediterranean Sea, while crustal movements occur at a more local scale (e.g., Crete). Hence, the average of all measured sea level movements on the entire basin will reflect the eustatic SLR, while local deviations from this average will reflect the local crust movements.

Sea Level Rise over the past 20 000 years (Wikipedia)
Sea Level Rise over the past 7 000 years (Wikipedia)
Sea Level Rise over the past 8000 years (Wikimedia Commons)

Many studies were conducted in recent decades to evaluate past eustatic SLR and to predict future eustatic SLR for the next century(s). The best known is the work of Kevin Fleming (1998)[3]. To make it short, the results are as follows, in round figures:

  • Predicted for the 21st c.: around 5 to 10 mm/year, and more
    depending on prediction model used;
  • Observed in the 20th c.: around 2 mm/year;
  • Observed in the past 1 500 years: around 0.3 mm/year,
    resulting in ca. 0.50 m eustatic SLR over this period;
  • Observed between 6 500 and 1 500 BP: around 0.7 mm/year,
    resulting in ca. 3.50 m eustatic SLR over this period;
  • Observed between 15 000 and 6 500 BP: around 14 mm/year,
    resulting in ca. 110 m eustatic SLR over this period.

These figures are in accordance with work of Nic Flemming (1973 & 1986)[1] who was the forerunner on this subject and with Christophe Morhange (2013)[2].

Since the rise of human civilisations around 6 500 BP, eustatic SLR has been around 4 m. This value must obviously be combined with local crustal movements which may have reached several meters uplift (e.g. Phalasarna in western Crete) or subsidence (e.g. Alexandria, Apollonia Cyrenaica, Portus Iulius, Rome, and many others) and sometimes both (Pozzuoli near Naples). The total change of sea level resulting from both eustatic and crustal movements is called “relative sea level rise”. Note that eustatic SLR is a fairly continuous phenomenon that may be expressed in mm/year over specific period of time as in the table above. However, crustal movements may be much more hectic (e.g., during earthquakes) and can therefore not be expressed in mm/year. Hence, the Relative SLR should not be expressed in mm/year. This RSLR was estimated from the vertical position of coastal structures such as quay walls, quarries and fish tanks, of horizontal rims of biological material, and of tidal notches. Fish tanks and biological rims are more accurate indicators of RSLR than port structures because of the uncertainty of the latter’s “functional height”. However, the precise dating of these indicators is often a problem.

As an example, let’s take the area of Rome, over a period of 2 000 years, studied in detail  by Goiran (2009)[4] based on an analysis of marine shells, and by Lambeck (2018)[5] based on an analysis of coastal fish tanks. The first concludes with a relative SLR of 0.8 m, and the latter with 1.22 m, hence both are quite close to 1.0 m. This relative SLR is thus composed of 0.5 m eustatic SLR + 0.5 m crustal subsidence.

Another interesting case is given by Morhange (2013) who shows that the relative SLR of 0.5 m in 2 000 years in Marseille-La Ciotat-Fréjus equals the eustatic SLR because no significant crustal movements occurred in this area during several millennia.

Relative SLR at Marseille, La Ciotat and Fréjus (Morhange, 2013).

A more controversial case is the Black Sea. It is accepted that it was once a fresh-water lake disconnected from the Mediterranean Sea by a sill in the Bosphorus located around -36 m below present sea level (deepest spot of the shallowest cross-section in the Bosphorus located in front of Dolmabahçe Palace).

Bosphorus sill gradually overflowed by global Sea Level Rise in the Mediterranean Sea (Gökasan, 2005) [8].
This configuration existed until around 9000 BP when, due to global eustatic SLR, Mediterranean water started to flow over the sill into the Black Sea-lake. The questions are: how deep was the lake water level at that time, and how fast did the water level rise? Even if the lake water level was much deeper than the Bosphorus sill, e.g. -80 to -100 m acc. to Yanchilina (2017)[6], flooding must have been rather progressive because, as mentioned above, global SLR was around 14 mm/year[7] … unless the sill in the Bosphorus collapsed, perhaps during an earthquake (more on this subject).

In any case, scholars agree on the fact that after reconnection with the Mediterranean Sea, the Black Sea water level followed the global eustatic SLR. This means that Neolithic and Bronze Age settlements were not affected by the controversy about the Black Sea water levels, i.e, Neolithic settlements dated around 6000-3000 BC might be found down to 15 m depth below the present sea level.

References

[1] Flemming, N.C., Webb, C.O., 1986, “Tectonic and eustatic coastal changes during the last 10,000 years derived from archaeological data”, Z. Geomorphol. Suppl. 62, (p 1–29).
Flemming, N.C., Czartoryska, N.M.G., Hunter, P.M., 1973, “Archaeological evidence for eustatic and tectonic components of relative sea level in the South Aegean”, 23rd Symposium of the Colston Research Society, Bristol, 1971, Pap. 23, (p 1-63).
Kayan, I., 2019, “Holocene Sea Level Changes and their Geoarchaeological Impacts on the Aegean Coast of Anatolia”, TINA, Maritime Archaeology Periodical, 2019:12, (p 11-35).

[2] Morhange, C., 2013, et al., “Relative Sea-Level Changes During Roman Times in the Northwest Mediterranean: The 1st Century A.D. Fish Tank of Forum Julii, Fréjus, France”, Geoarchaeology: An International Journal, 28, (p 363–372).

[3] Fleming, K., et al., 1998, “Refining the eustatic sea-level curve since the Last Glacial Maximum using far- and intermediate-field sites”, Earth and Planetary Science Letters 163, (p 327–342).

[4] Goiran, J-P., Tronchère, H., Collalelli, U., Salomon, F., Djerbi, H., 2009, “Découverte d’un niveau marin biologique sur les quais de Portus : le port antique de Rome”, Revue Méditerranée, 112 | 2009, (online), (10 p).

[5] Lambeck, K., Anzidei, M., Antonioli, F., Benini, A., Verrubbi, V., 2018, “Tyrrhenian sea level at 2000 BP: evidence from Roman age fish tanks and their geological calibration”, Rendiconti Lincei. Scienze Fisiche e Naturali, Satellite Geodetic Positioning for Geosciences, Roma, 2017, (12 p).

[6] Yanchilina, A., et al., 2017, “Compilation of geophysical, geochronological, and geochemical evidence indicates a rapid Mediterranean-derived submergence of the Black Sea’s shelf and subsequent substantial salinification in the early Holocene”, Marine Geology, 383 (2017), (p 14-34).

[7] A simple hydraulic computation with a sill at -36 m shows that this global SLR would induce a rise of the Black Sea level (from -90 m) within around 200 years, inducing a gradually increasing SLR in the Black Sea not exceeding 1 m/year. This is fast, but it is not a catastrophic flood. The « deluge hypothesis » can only be explained by collapse of (a part of) the Bosphorus sill. Further details and hydraulic computations are provided in the section on “The Bosphorus“).

[8] Gökaşan, E., et al., 2005, “Evidence and implications of massive erosion along the Strait of Istanbul (Bosphorus)”,  Geo-Mar. Lett. 25, p 324–342.
